Rovema CMK Operator’s Manual
Section 1: Introduction
200246 CMK Operators Manual (02/06/2006) 1-7
Introduction to the CMK
The below legend corresponds to the previous figure.
Legend
1- HMI Display
2- Drive (Not in view)
3- Carton Supply
4- Carton Magazine
5- Carton Erector
6- Carton Drive Chain
7- First Flap Inserter
8- Barrel Loader
9- Printer/Coder
10- Second Flap Inserter
11- Gluing Station
12- Carton Discharge
13- Central Lubrication
14- Connection Monitoring
15- Bucket Conveyor
16- Height Adjustment
17- Length Adjustment
18- Angle Encoder
19- Carton/Bag Reject Conveyor
20- Electrical Cabinet
