Rovema CMK Operator’s Manual
Section 7: Working with Components
200246 CMK Operators Manual (02/06/2006) 7-11
Change Over and Adjustments
Change Over-Continued
13. Loosen Flap Closers to and adjust to new carton size.
14. Replace side guides previously removed.
15. Load new recipe on HMI.
16. Adjust the Barrel Loader position so the Guides and Pushers are in the
center of the new bucket sizes. Note: The Bucket Loader should still be in
the Upper position as not to contact the buckets until it has been properly
centered. Access “Main Parameters Screen 3”, use the “Barrel Loader
Home Offset” parameter to adjust the location of the pushers. A larger
parameter value will move the pushers in the clockwise position (move
them to the left). A smaller value will move the pushers in the
counterclockwise direction (move them to the right). After changing this
value, run the machine in jog mode to move the pushers to their new
location. Then, stop the machine and verify that the pushers are centered
in the center of the buckets, if not repeat the process. Note: Do this with
the Barrel Loader in the upper position as not to contact the bucket walls.
17. After the Barrel Loader has been properly centered and positioned in the
Jog mode, replace the Pusher Guides and the Pushers with the new ones
required for the new setup.
18. Run the cartoner in Jog mode and make any additional adjustments as
required.
19. Document and record all the final dial and scale settings for future
reference.
Note: Verify all adjustments are correct prior to running the machine as
incorrect adjustments will cause damage to the machine.
