Loading a Media Roll (When the Optional Cutter Unit Is Installed)
116
3. Load the media roll.
Load the media roll from above so the print side faces the print head (5).
If the media roll is loaded correctly, the flaps (6) stand up.
• There are two wind directions for the media. The illustration is for face-out media.
4. Pull the paper out from the product so it goes under the left and right tabs (7), and
pass it through the media discharge outlet (8).
5. Close the top cover.
Push both ends of the top cover, and close it firmly until it clicks.
To Next Page
