SATO CT4-LX User Manual

31
Parts Identification
Front View
(1) LED indicator
(2) NFC antenna location
(3) LCD/Touch panel
(4) Media discharge outlet
(5) Cover open latch
(6) (Power/Home) button
To power on the product, press the (Power/Home) button until the LED lights blue.
While the product is powered on, press the (Power/Home) button to switch to the Home
screen. (The Home screen does not appear while print jobs remain in the product.)
To power off the product, press the (Power/Home) button for more than 2 seconds, and
then follow the on-screen instructions.

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
