USB Interface
520
USB Interface
This interface complies with the USB 2.0 standard.
Install the USB driver to the computer before use.
Basic Specifications
Connector USB Type B connector
Protocol
• STATUS4
• STATUS5
Power Supply BUS Power through cable
Pin Assignments
Pin No. Description
1 VBus
2 -Data
3 +Data
4 GND
Cable Specifications
Cable Connector USB Type B connector
Cable Length 5 m (16.4 feet) or less
• Specifications are subject to change without notice.
