SATO CT4-LX User Manual

127
Loading the Ribbon
• The print head and its surroundings are hot after printing. Be careful not to get burned.
• Touching the edge of the print head with your bare hand could cause injury.
• Use our specified supply products for the product, for optimum print quality.
• Before loading the ribbon to the product, insert one core adapter into the carbon ribbon
and one into the ribbon core.
1. Press the cover open latch (1) to open the top cover (2).
2. Pull the (ribbon cover open) marks (3) toward the front to open the ribbon unit (4)
toward the front.

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
