SATO CT4-LX User Manual

[SIPL]
224
[Tilde]
Set the tilde (~) code.
The setting range is from 0 to 255.
• You need to set different values for each code (caret, delimiter, tilde).
[Clock Format]
Set the date format.
The options are as follows:
• [(none)]
• [MM/DD/YY (24-hour clock)] (Example: 01/24/17 (13:45))
• [MM/DD/YY (12-hour clock)] (Example: 01/24/17 (01:45))
• [DD/MM/YY (24-hour clock)] (Example: 24/01/17 (13:45))
• [DD/MM/YY (12-hour clock)] (Example: 24/01/17 (01:45))
[Default Font]
If you are using the multilingual fonts in the product, select a default font from the list.
[SIPL]
To use SIPL as a printer command, set the following items:
[Font Settings]
Set the font.
The setting items are as follows:
[Code Page]
Select the code page to be used from the list.
[New Font Encoding]
Enable or disable new font encoding.
• Contact your SATO sales representative for more information about the new font.
[Proportional]
Set whether to print each character using a proportional pitch or fixed pitch.
Print each character with a proportional pitch.

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
