SATO CT4-LX User Manual

Adjusting the Buzzer Volume
384
Adjusting the Buzzer Volume
The adjustment procedure for the buzzer volume when an error occurs is as follows:
1. Tap [SETTINGS] on the Home screen or Offline screen.
2. Input the password if it is enabled.
3. Tap [System].
You can switch the screen by tapping / or sliding the screen to the left or right.
4. Tap [Sound] > [Volume].
5. Change the setting value.
The setting range is from 0 to 8.
0 is the lowest and 8 is the highest.
If you set the volume to 0, it mutes the sound.
6.
Tap to save the setting value.

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
