SATO CT4-LX User Manual

RS-232C Interface Connection (Optional)
96
• To use the printer driver, the communication protocol must be set to Status4. (The
initial value of the communication protocol for the product's LAN interface is Status4
ENQ.)
RS-232C Interface Connection (Optional)
Check if the RS-232C kit is attached to the product.
Connect the interface cable when the product is powered off.
Connect the RS-232C cable to the RS-232C connector (1).
Configure the interface settings of the product according to the interface settings of the computer.
The communication conditions of the RS-232C interface can be set through the product's [Interface]
menu or the All-In-One Tool.

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
