SATO CT4-LX User Manual

535
Usable Ribbon
• Use our specified supply products.
Item Description
Size
Length
Maximum 100 m (328 feet) (maximum outside diameter φ39 mm (1.54"))
Width
45 – 111 mm (core width: 45 mm (1.77"), 76 mm (2.99"), 111 mm (4.37"))
• The maximum length of the ribbon varies depending on the
ribbon type.
• Use the ribbon that is wider than the media.
Wind Direction Face-out
Winding Method Winding on core

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
