Loading a Media Roll (When the Optional Linerless Cutter Unit Is Installed)
118
Loading a Media Roll (When the Optional Linerless Cutter Unit Is
Installed)
• The print head and its surroundings are hot after printing. Be careful not to get burned.
• Touching the edge of the print head with your bare hand could cause injury.
• Be careful not to touch the cutter blade.
1. Press the cover open latch (1) to open the top cover (2).
2. While pulling the slide lever (3), move the right side media guide (4) to adjust the
width of the media guide to match the width of the media.
To Next Page
