SATO CT4-LX User Manual

153
Media Sensor Type
The product adjusts the print position precisely by detecting I-marks or Gaps on the media (label)
using media sensors.
The I-marks or Gaps on each type of media are as follows:
I-mark Gap
(1) Feed direction
Set the sensor type to detect the print position according to the media to be used.
The sensor types can be set through the Startup Guide, Media Startup, and Media Profiles
Registration. Alternatively, the following procedure can be used.
1. Tap [SETTINGS] on the Home screen or Offline screen.
2. Input the password if it is enabled.
3. Tap [Printing].

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
