SATO CT4-LX User Manual

279
[Print Module]
Shows information related to the print module in the product.
The item is as follows:
Main
Shows the Main firmware information.
[Sensor Module]
Shows information related to the sensor module in the product.
The items are as follows:
Boot
Shows the Boot firmware information.
Main
Shows the Main firmware information.
[FPGA Version]
Shows the FPGA version of the product.
[Counters]
Shows information about the product's counter.
• Only SATO authorized service personnel are permitted to clear the counter.
The setting items are as follows:
[Head]
Shows information about the counter for the product's head.
The items are as follows:
Life
Shows the current print distance.
Head 1
Head 2
Head 3
[Head 1] shows the current print distance. When you replace the print head, the value of [Head
2] appears in [Head 3] and the value of [Head 1] appears in [Head 2]. [Head 1] will start to count
from 0 again.

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
