SATO CT4-LX User Manual

115
Loading a Media Roll (When the Optional Cutter Unit Is Installed)
• The print head and its surroundings are hot after printing. Be careful not to get burned.
• Touching the edge of the print head with your bare hand could cause injury.
• Be careful not to touch the cutter blade.
• Adjust the cut position so as not to cut the label.
1. Press the cover open latch (1) to open the top cover (2).
2. While pulling the slide lever (3), move the right side media guide (4) to adjust the
width of the media guide to match the width of the media.

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
