Adjusting the Base Reference Point
About the Base Reference Point
The base reference point is the point at which one determines the print position and stop/cut/
dispensing position.
The base reference point differs depending on the print mode or media sensor you use.
Continuous Mode
I-mark label Gap label
(1) Feed direction
(2) Print position
(1) Feed direction
(2) Print position
Tear-Off Mode
I-mark label Gap label
(1) Feed direction
(2) Tear-off position
(3) Print position
(1) Feed direction
(2) Tear-off position
(3) Print position
Dispenser Mode

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
