SATO CT4-LX User Manual

About the Base Reference Point
368
I-mark label Gap label
(1) Feed direction
(2) Dispensing position
(3) Print position
(1) Feed direction
(2) Dispensing position
(3) Print position
Cutter/Partial Cutter Mode
I-mark label Gap label
(1) Feed direction
(2) Cut position
(3) Print position
(1) Feed direction
(2) Cut position
(3) Print position
Linerless Cutter Mode
I-mark Linerless Label
(1) Feed direction
(2) Cut position
(3) Print position

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
