SATO CT4-LX User Manual

191
(Standard mode)
[BCC]
Enable or disable the BCC check function.
Available only if you have selected [STATUS5] in the [Flow Control] menu.
[Delay Reply ENQ]
Set the period to delay status reply to status request command ENQ.
This can be set only if you have selected anything other than [STATUS4] in the [Flow Control] menu.
The setting range is from 0 to 9999 ms.
• Normally, keep this setting at the initial value.
[Status4 Cyclic Response]
Set the interval for the cyclic status response.
This can be set only if you have selected [STATUS4] in the [Flow Control] menu.
The setting range is from 100 to 999 ms.
[Proxy (LAN)]
Set a proxy.
• The proxy set here is shared with the settings in [Wi-Fi] > [Wi-Fi Setting] > [Proxy (Wi-
Fi)].
The setting items are as follows:
[Enabled]
Enable or disable use of proxy.
• To enable a proxy, you need to set [Server] and [Exclude].
[Server]
Set the name or IP address of the proxy server.
Example: http://192.168.1.11:3128
• Server should be set with a valid name or IP address and port number.
• Hold "." to input a colon (:).

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
