SATO CT4-LX User Manual

Adjusting the Media Stop Position
374
5. Change the setting value.
The setting range is as follows:
Resolution Setting range
203 dpi (1 dot = 0.125 mm (0.0049")) -30 to +30 dots
305 dpi (1 dot = 0.083 mm (0.0033")) -45 to +45 dots
• Do not allow the distance between [Pitch] and [Offset] after adjustments to exceed the
size of 1 label (including liner).
• You can change the units to dots, " (inches), or mm in the [System] > [Regional] >
[Unit] menu.
6.
Tap to save the setting value.
7.
Press the (Power/Home) button to show the Home screen.

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
