SATO CT4-LX User Manual

443
• Align the rough side of the cleaning sheet adjacent to the top cover.
6. Close the top cover.
Push both ends of the top cover, and close it firmly until it clicks.
• When closing the top cover, be careful not to pinch your fingers.
7. Using two hands, pull the cleaning sheet away from the product.
8. After you pull out the cleaning sheet, repeat steps 2 through 7, two or three more
times.
When no more dirt appears on the cleaning sheet after you have pulled it out, stop repeating these
steps.
9. Press the cover open latch to open the top cover.

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
