SATO CT4-LX User Manual

506
Error Message 1123 (Write-Lock Tag Is Used or Power Is not Strong
Enough)
When there is an error with the product, the error message appears on the screen.
Tap the error number button to show the details screen.
Check the cause and countermeasure, and then take appropriate action.
To clear the error:
Cause and Countermeasure Reference
Cause (1)
Tried to write to an inlay that was write-locked or to an
inlay that had more than 64 digits of EPC written to it.
Countermeasure (1)
Use tags that are not locked.
-
Cause (2)
Tried to write to an inlay when the writing power is low.
Countermeasure (2)
Adjust [Write Power]/[Read Power].
Write Power
Read Power
Contact your SATO technical support if the error cannot be resolved.
Contact Information for When You Are in Trouble
• You cannot use an RFID tag that has caused an RFID tag error. An error message is
printed on the RFID tag that caused the error.

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
