Connector Pin Specifications
Pin
No.
I/O Description
1 - Data Carrier Detect
2 Input Receive Data
3 Output Transmit Data
4 Output Data Terminal Ready
5 Reference Signal Ground
6 Input Data Set Ready
7 Output Request To Send
8 Input Clear To Send
9 - Not connected
Cable Specifications
Cable Connector DB-9 Male or equivalent
Cable Length 5 m (16.4 feet) or less
• When using the READY/BUSY control, make sure that the product is in power on
mode before you send the data from the host.
• With communication protocols such as XON/XOFF, STATUS3, STATUS4 or STATUS5,
a receive buffer full error will occur when the received data is more than the receive
buffer size (2.95 MB). When sending data, monitor the status of the product and keep
the size of the data that is sent to less than 2.95 MB.
• A parity error is detected when an error occurs after receiving the start code <A>
command.
• Specifications are subject to change without notice.

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
