554
OCR-A Font
The OCR-A font is a bitmap font. The basic size varies depending on the print resolutions as follows:
Print Resolution Basic Font Size
203 dpi (8 dots/mm) 22 dots H x 15 dots W
305 dpi (12 dots/mm) 33 dots H x 22 dots W
This supports fixed pitch only.
The figure below is a font sample when the print resolution is 305 dpi (12 dots/mm).
