12 Injection Port
12.1 Packed Column Injection Port (Dual INJ)
121
GC-2014
12.1.1.2 Parameter list
TEMP
Range: 0.0−400.0 °C, Default: 25.0 °C
Set the temperature of the injection port.
Keep the injection port temperature as low as is practical to increase the service life of
the temperature sensor. In order to instantly vaporize samples inside the injection port,
set the injection port temperature approximately 30 °C above the column oven
temperature (final temp). Due to the minute quantity of sample injected, the sample
vaporizes at temperatures lower than the boiling point of sample elements. To set the
injection port maximum temperature limit, refer to “16.6.4 Setting the maximum
temperature limits” in “16.6 GC Configuration”.
12.1.1.3 PF menu
PF menu Description
Reference
section
Print Prints the injection port temperature on Chromatopac.
――
Next Inj
Toggles among the setup screeens if two or more injection ports are
installed in this system.
The [INJ] key can also be used to switch screens.
――

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
