Shimadzu GC-2014 Instruction Manual

231
16 Special Functions
16.4
16.
GC-2014
16.4Pre-Run Program
The Pre-Run program controls flow controllers and relays before the analysis starts.
16.4.1 Screen description
Select “4. PRE-RUN” from the [FUNC] key screen to display the Pre-Run screen shown in
Fig. 16.4.1. A Pre-Run program is executed after the [START] key is pressed, but before an
analysis.
While the Pre-Run program is running, the elapsed time is displayed in the “Time” field on
the [MONIT] key screen.
Program steps do not need to be entered in order. After you finish editing the Pre-Run
program, programs are automatically sorted.
More than one step can be set for the same time. The specified actions are executed at the
same time.
16.4.2 PF menu
Fig. 16.4.1 Pre-Run program main screen
PF menu Description
Reference
section
New Creates a new Pre-Run program. 16.4.3
Del Line Deletes the program at the current cursor position.
――
Chng Line Changes over the screen of Pre-Run program every line.
――
Print Prints the program to the Chromatopac.
――

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
