Shimadzu GC-2014 Instruction Manual

14 Diagnosis
14.1 Standard Diagnosis
179
GC-2014
14.1.9 Diagnosis results
Press [Details] (PF menu) from the screen shown in Fig. 14.1.4 once the standard diagnosis
is have stopped or ended; the Test Result screen shown in Fig. 14.1.5 appears.
Press [Details] (PF menu) from the standard diagnosis screen shown in Fig. 14.1.4 to
display the results of the last test since the power was turned on. Once the power is turned
off, the diagnosis results are cleared.
14.1.10 PF menu
Fig. 14.1.5 Diagnosis results
PF menu Description
Reference
section
Print Prints out the results of the diagnosis to a Chromatopac.
――

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
