16 Special Functions
16.3 Time Program
227
GC-2014
16.3.5 Time Program parameters
NOTE 1) “Relay” description
AC On/Off: Turns the power supplied to the AC connector on the power controller PCB on/off.
Event of On/Off point: Turns the relay contact on the PRG PCB (option) on/off.
Event91 and Event92: Switches a-contact and b-contact of each relay on the CPU PCB
(standard).
Event of PRG: Switches a-contact and b-contact of each relay on the PRG PCB (option).
Blower, Cooling Fan, CRG INJ and CRG Column: Turns the power of each option on/off.
Parameter Description
Relay
NOTE 1)
Detector
Range
Sets range or attenuation for the detector configured in the
analytical line.
Polarity
Changes the polarity between “+” and “-” for TCD configured in the
analytical line.
Current Sets current for the detector configured in the analytical line.
NOTE 2)
Zero Adj
Turns on/off zero adjustment for the detector configured in the
analytical line.
Flame Ignites / Extinguishes the flame.
FTD
Turns on/off voltage feedback to make current constant for FTD
configured in the analytical line.
Detector controller
Turns on/off control of detector configured in the analytical line
during analysis program.
Flow
controller
Refer to
NOTE 3).
Splitter Ctrl Opens/closes splitter.
Flow controller On/Off
Turn carrier gas, septum purge, detector gas, APC, and AMC (AUX
AMC and AMC. LR) on/off.
High press inj mode Turns high pressure injection mode on/off.
Gas saver Turns gas saver function on/off.
Temperature
INJ1, INJ2, DET1, DET2,
AUX3, AUX4, AUX5
Use a time program to change temperature of heated zones, which
cannot be programmed.
Stop
NUMBER
OF TIMES
OF RUN
End of
program
Specify the number of times to execute the GC program. Then,
either the program stops or the next file is executed. If greater than
2, the choices are “continuous” or “pause at each run.” For an
AOC, select “continuous”. When “pause at each run” is selected,
the program executes continuously at set intervals.
If another program (such as a temperature program) is running
when time program execution time expires, priority is given to
running the program. When the current program finishes, the time
program stops or file is changed to another file.
0: FILE
0−9 Load
Other Set the parameter to input event No..(Refer to “17.4 Event No.”.)
Relay
Relay
Switch point
Event 91,92 V91−92 Point A or B
PRG V93−94 Point A or B
On/Off point Event 1−16 On or Off
AC On/Off
Oven Exhaust Fan On or Off
Cooling Fan On or Off
CRG INJ On or Off
CRG Colum On or Off
