Shimadzu GC-2014 Instruction Manual

6 Basic Key Operation
6.1 Keypad Description and Operation
70
GC-2014
6.1.3 Status indicators
Three status lights indicate the GC status regardless of the screen display. The STATUS,
TEMP and FLOW lights indicate the GC status, the temperature control status and the gas
control status, respectively. Light color and illumination are also used to indicate instrument
parameter status.
Q STATUS indicator
Q TEMP indicator
Q FLOW indicator
Color Status Meaning
Off Power is OFF.
Green
On System is ready.
Blinking Program, like the temperature program, are executing.
Yellow
On System is OFF. Alternatively, the system is ON, but is not ready.
Blinking Diagnosis, baking or flow controller calibration is being executed.
Red On An error has occurred in system.
Color Status Meaning
Off Temperature control is not performed.
Green
On All temperature controlled zones are ready.
Blinking Temperature program is running.
Yellow
On One of the temperature controlled zones is not ready.
Blinking Temperature program is finished, and system is being cooled.
Red On An error related to temperature control has occurred.
Color Status Meaning
Off Gas control is not performed.
Green
On All gas control lines are ready.
Blinking
Pressure/flow rate program is running, it is sampling time, or
high pressure injection is occurring.
Yellow
On One of the gas control lines is not ready.
Blinking
Pressure/flow rate program is finished, and default values are
being set.
Red On An error related to gas control has occurred.

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
