Shimadzu GC-2014 Instruction Manual

271
17.1
17.17.
GC-2014
17 Printing
17.1Printing
17.1.1 Connection to Chromatopac
Connect the gas chromatograph to the Chromatopac, then press [Print] (PF menu) from the
GC screen to print to the Chromatopac.
For the GC and Chromatopac connection, refer to “2.4 Connecting a RS-232C Cable to the
Chromatopac C-R8A”.
17.1.2 Parameters to be printed
17.1.2.1 Program
The current file program can be printed.
This includes the following screens: temperature program (COL, INJ1, INJ2), pressure
program (CAR1, CAR2, CAR3), flow rate program (CAR1, CAR2, CAR3) and split ratio
program (CAR1, CAR2.)
Press [Print] (PF menu) from any screen to print the same parameters for a saved pro-
gram.
Fig. 17.1.1
- COLUMN OVEN TEMP PROGRAM -
RATE TEMP TIME
0 ------- 100.0 1.00
1 6.00 220.0 25.00
- INJ1 TEMP PROGRAM -
RATE TEMP TIME
0 ------- 25.0 0.00
- INJ1 PRESSURE PROGRAM -
RATE TEMP TIME
0 ------- 100.0 0.00
- INJ1 SPRIT RATIO -
TIME RATE
0 ------- -1.0
- END -

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
