Shimadzu GC-2014 Instruction Manual

18 Error Messages
18.1 Error Messages
286
GC-2014
18.1.2 Temperature control errors
Heat loss
This message appears when heat loss is substantial. The oven door may be open or the
insulation has a hole. If the column oven door is open, close it and select “Reset Error.” If the
insulation has a hole in it, turn off the power of the unit, repair the hole, and then restart the
system.
This error may not occur even when the door is open when the column oven temperature is
set at a certain range or the temperature around the unit is a certain level.
Temperature increase limit over
These messages appear when the maximum temperature limit has been exceeded. Press
“Ignore Error” and change the maximum limit temperature. If the confirmation screen to reset
the error appears again, press “Reset Error.”
Code Message CS
1001 Heat is escaping Yes
Code Message CS
1002 COL temp exceed the limit Yes
1003 INJ1 temp exceed the limit Yes
1004 DET1 temp exceed the limit Yes
1005 INJ2 temp exceed the limit Yes
1006 DET2 temp exceed the limit Yes
1007 AUX3 temp exceed the limit Yes
1008 AUX4 temp exceed the limit Yes
1009 AUX5 temp exceed the limit Yes

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
