Shimadzu GC-2014 Instruction Manual

18 Error Messages
18.1 Error Messages
287
GC-2014
Temperature sensor errors
When one of these messages appears, the temperature sensor may have failed. The sensor
cannot be used in this condition and replacement or repair is required. Turn off the system
and contact your Shimadzu representative.
Unstable temperature with CRG
This message appears when cooling is impossible because of insufficient coolant, etc.
If there is no coolant, turn off the system, replace the coolant, and then restart the system.
This message may appear when cooling is impossible because the oven door is open. In
this case, close the door and press “Reset Error.”
Code Message CS
1010 COL sensor is short circuit Yes
1011 INJ1 sensor is short circuit Yes
1012 DET1 sensor is short circuit Yes
1013 INJ2 sensor is short circuit Yes
1014 DET2 sensor is short circuit Yes
1015 AUX3 sensor is short circuit Yes
1016 AUX4 sensor is short circuit Yes
1017 AUX5 sensor is short circuit Yes
1018 COL sensor is down Yes
1019 INJ1 sensor is down Yes
1020 DET1 sensor is down Yes
1021 INJ2 sensor is down Yes
1022 DET2 sensor is down Yes
1023 AUX3 sensor is down Yes
1024 AUX4 sensor is down Yes
1025 AUX5 sensor is down Yes
1026 COL sensor is error Yes
1027 INJ1 sensor is error Yes
1028 DET1 sensor is error Yes
1029 INJ2 sensor is error Yes
1030 DET2 sensor is error Yes
1031 AUX3 sensor is error Yes
1032 AUX4 sensor is error Yes
1033 AUX5 sensor is error Yes
Code Message CS
1034 COL CRG cannot be controlled Yes

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
