Shimadzu GC-2014 Instruction Manual

18 Error Messages
18.1 Error Messages
288
GC-2014
Overheat
An error may have occurred in the temperature control circuit.
Turn off the system and contact your Shimadzu representative.
Relay/heater control circuit errors
An error may have occurred in the control circuit.
Turn off the system and contact your Shimadzu representative.
Detector temperature setting error
These messages appear when the Detector temperature setting value is smaller than that of
the Oven. Increase the Detector temperature.
To have the Detector temperature lower than the column oven temperature, set “No” on
Protection against contamination (PF menu) on the screen to set the maximum temperature
on configuration setting.
Code Message CS
1036 Overheat is sensed Yes
1037 COL temp controller broken No
1038 INJ1 temp controller broken No
1039 DET1 temp controller broken No
1040 INJ2 temp controller broken No
1041 DET2 temp controller broken No
1042 AUX3 temp controller broken No
1043 AUX4 temp controller broken No
1044 AUX5 temp controller broken No
Code Message CS
1045 COL relay error No
1046 INJ1-DET2 relay error No
1047 AUX3-AUX5 relay error No
1048 Heater controller error No
Code Message CS
1049 DET#1 set temp is low No
1050 DET#2 set temp is low No
1051 DET#3 set temp is low No
1052 DET#4 set temp is low No

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
