Shimadzu GC-2014 Instruction Manual

18 Error Messages
18.1 Error Messages
289
GC-2014
18.1.3 Pressure/flow rate errors
Leaks
The pressure cannot reach the set value. Check whether gas is supplied and whether gas is
leaking from connections.
Gas may be leaking in locations other than the ones displayed.
(Example) If the purge flow rate is too low because of the leakage of carrier gas line, the message
“Purge leaks” appears in stead of the indication of ESC or TFC leakage.
Code Message CS
2005 CAR1 purge leaks Yes
2006 CAR2 purge leaks Yes
2007 CAR3 purge leaks Yes
2014 DetAPC1 makeup gas leaks Yes
2015 DetAPC1 hydrogen leaks Yes
2016 DetAPC1 air leaks Yes
2017 DetAPC2 makeup gas leaks Yes
2018 DetAPC2 hydrogen leaks Yes
2019 DetAPC2 air leaks Yes
2020 DetAPC3 makeup gas leaks Yes
2021 DetAPC3 hydrogen leaks Yes
2022 DetAPC3 air leaks Yes
2023 DetAPC4 makeup gas leaks Yes
2024 DetAPC4 hydrogen leaks Yes
2025 DetAPC4 air leaks Yes
2026 APC1 leaks Yes
2027 APC2 leaks Yes
2028 APC3 leaks Yes
2029 APC4 leaks Yes
2030 APC5 leaks Yes
2031 APC6 leaks Yes
2032 APC7 leaks Yes
2033 APC8 leaks Yes
2034 APC9 leaks Yes
2035 APC10 leaks Yes
2036 APC11 leaks Yes
2037 APC12 leaks Yes
2038 APC13 leaks Yes
2039 APC14 leaks Yes
2040 APC15 leaks Yes
2041 APC16 leaks Yes
2042 APC17 leaks Yes
2043 APC18 leaks Yes
NOTE

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
