Shimadzu GC-2014 Instruction Manual

14 Diagnosis
14.5 Standard Installation Test
193
GC-2014
14.5.3 Test procedure
(1) Specify the analytical conditions file of the standard installation test.
Example: Load “File 1” using [File] (PF menu) of the [SET] key.
(2) Configure the injection port and the detector used to execute the standard installation
test in an analytical here.
However, if two or more analytical lines have been configured, the lowest No. analytical
line is set with the test conditions.
In the standard installation test, only one detector can be set per analytical line. If two or
more detectors are set, an error message appears.
(3) Set the dimensions of the column installed.
Example: Set the dimensions of the column using [Column] of the [FLOW] key.
(4) Press [Load] (PF menu) to load the analytical conditions of the standard installation test.
(5) If the analytical condition need to be changed for the installation test, change the
parameters.
(6) Make an injection, then verify whether the data has been acquired correctly.
(7) When analysis finishes, press [Unload] (PF menu) to return the analytical conditions to
their former status.

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
