Shimadzu GC-2014 Instruction Manual

14 Diagnosis
14.2 Log Reading Menu
186
GC-2014
14.2.6 Error log
When “4. ERROR LOG” is selected, the log of all errors which have been displayed is
shown.
(1) Screen description
Select “2. LOG READING MENU” from of the [DIAG] key main screen, then select “4.
ERROR” to display the screen shown in Fig. 14.2.6.
Up to 100 logs are saved. If the number of logs exceeds 100, existing logs are deleted
starting from the oldest.
If there are more items than can be displayed on one screen, scroll through the screen using the left
and right arrow keys.
(2) PF menut
Fig. 14.2.6 Error log screen
PF menu Description
Reference
section
Clear Log
Deletes all displayed logs.
When [Clear Log] (PF menu) is pressed, the screen changes and the
message “Clear log with PF2” appears. Press [Clear Log] (PF menu) to
clear the log.
――
Print Prints the error log to a Chromatopac.
――
NOTE

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
