Shimadzu GC-2014 Instruction Manual

7 Starting and Stopping the GC [SYSTEM]
7.1 [SYSTEM] Key Main Screen
81
GC-2014
7.1.3 PF menu
PF menu
item
Description
Reference
section
Start GC Starts GC according to the parameters on the [SYSTEM] key main screen.
――
Stop GC
Starts GC according to the parameters on the [SYSTEM] key main screen.
If no program is running,the stop time countdown begins immediately when
[Stop GC] (PF menu) is selected.
If [Stop GC] is selected while a program is running, the stop time countdown
begins after the program finishes.
――
File
Displays the file list to change to another method file.
On this sub screen, select files to load, edit, copy, initialize and rename.
8.2
Clean Up
Sets clean up parameters.
In system ON status, select direct operation (PF menu) to run the clean up.
7.2
Start Seq
Sets the parameters for the next GC start up.
Start time, detector and clean up parameters on this sub screen are
immediately reflected on the [SYSTEM] key main screen.
7.3
Stop Seq
Sets the stop procedures.
This item is not displayed in system ON status.
7.4
Maint INJ
Prepares the GC for maintenance of the injection port (replacement of
septum, glass insert, etc.) .
When GC is ready for maintenance, the message “GC is ready for maintenance”
appears.
4.3 General
maintenance
procedures
in the operation
manual
Anal.
Restores the GC for analysis after performing injection port maintenance.
When pressed after maintenance of injection port is completed.
――

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
