Shimadzu GC-2014 Instruction Manual

6 Basic Key Operation
6.1 Keypad Description and Operation
68
GC-2014
6.1.1 Keypad operation
The keypad is used to operate the system and make parameter settings. The table below
shows the function of each key.
Name Function
START key Starts the temperature program, pressure/flow rate program and time program.
If a Pre-Run program is set, the Pre-Run program starts.
STOP key Stops the program.
DIAG key Performs unit self-diagnosis.
Also, used for maintenance functions such as confirmation of various logs, part
replacement status, and standard signal out put.
SYSTEM key Starts/stops GC.
Manages the analytical condition file.
PF key Selects the PF menu displayed at bottom of the screen.
(PF = programmable function)
Toggle key Toggles through the PF menu displayed at bottom of the screen.
MONIT key Monitors the GC status and analysis status.
Displays the GC temperature, pressure and flow rate status for each heated zone,
as well as chromatograms.
SET key Accesses commonly-used items, such as temperature, pressure and flow rate for
each component on one screen.
Manages the analytical condition file like the [SYSTEM] key.
FUNC key Accesses less frequently used items.
COL key Sets the oven temperature program.
FLOW key Sets the carrier gas flow rate parameters, such as pressure, flow rate and split
ratio.
INJ key Sets the temperature of injection port (or temperature program for an OCI/PTV).
DET key Sets the detector temperature, range and current or other detector-related param-
eters.
OPTION key Sets the parameters for auto injector, AUX temperature controller, AUX APC, AUX
AMC, and CRG.
HELP key Describes the procedure and sugggests valid parameter ranges.
Jumps to a desired item using an index function.
Cursor key
[ △ ], [ ▽ ], [] and []
Moves cursor up, down, left and right.
A blinking cursor indicates the location of parameter value entry.
[ ] and [ ] keys may be used to change the selection.
Numeric keys
[0] ~ [9]
Enter numeric values.
Clear key
[CE] key
・ Clears the current numeric value.
・ Clears display and alarm during an error.
ENTER key Validates parameter input or item selection.
△
△
△
△
+
-

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
