Shimadzu GC-2014 Instruction Manual

15 Optional Devices
15.1 Auto Injector Parameters
199
GC-2014
15.1.6 PF menu
15.1.7 Other AOC parameters
Select [OtherPara] (PF menu) from the AOC main screen to display the other parameters
screen shown in Fig. 15.1.3.
Specify options and AOC custom parameters.
PF menu Description
Reference
section
Set
Analyzes the vial No. specified after the analysis of the current sample is
finished.
――
Fig. 15.1.3 Additional AOC parameter setup

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
