Shimadzu GC-2014 Instruction Manual

17 Printing
17.1 Printing
272
GC-2014
17.1.2.2 AOC parameters
The current file’s AOC parameters and the parameters of AOC settings can be printed.
The AOC2 parameters can be printed when an AOC2 is configured in the analytical line.
All printed items are listed by command name. To match command names to screen
items, refer to “17.2 AOC commands”.
Fig. 17.1.2
17.1.2.3 Main parameters
Press [Print] (PF menu) from the [SET] key to print the temperature valves for all heated
zones, the CAR1/2 pressure value, and the total flow rate value from the current file.
Fig. 17.1.3
- AOC PARAMETER -
AOC1 AOC2
WRPT 2 2
WMOD 1 1
REPT 1 1
IVOL 1.0 1.0
WPRS 0 0
PUMP 5 5
WTPP 0.2 0.2
WAIT 0.0 0.0
ISPD 2 2
SSPD 1 1
SAND 0 0
SOLV 0 0
SINT 0 0
SSNO 0 0
SNO2 0 0
AAIR 0 0
USPD 2 2
DSPD 2 2
HIGH 0 0
LOWS 0 0
- GC PARAMETER 0:FILE0 -
COLUMN OVEN TEMP 25.0
INJ1 TEMP 25.0
DET1 TEMP 25.0
INJ1 PRESS 100.0
INJ1 FLOW 50.0
- END -

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
