When connecting the GC to a C-R7A/CR-7A plus for the first time, or replacing
the Chromatopac, set the detector signal output to “Off” and perform
calibration. (For the calibration procedure, refer to “2.2 Outputting Analog
Signals to the Chromatopac”.)
Linear...Select linear when connecting the GC to any Chromatopac other than the C-
R8A/C-R7A/CR-7A plus.
When connecting the GC to the C-R8A/C-R7A/C-R7A plus and setting the
“ANALOG SIGNAL TYPE” to “Linear,” the optional signal cable (linear P/N 221-
47251-92) is required.
13.1.2.3 PF menu
PF menu Description
Reference
section
Ignite
Reduces the air flow rate, heats filament, and ignites detector when
pressed when “FLAME” was set to “Off”.
If “AUTO IGNIT” is set to “On” on the [SYSTEM] key screen, the detector is
automatically ignited after each setting reached the setting value.
13.2.2.4
Det Gas
Sets the flow rate of makeup gas, hydrogen and air if the advanced
Pressure Control (APC) is installed.
13.2.3
Ign. Set
If the Advanced Pressure Control (APC) is installed, you can set automatic
ignition and automatic re-ignition. Default value is “On”.
―――
Next Det
Toggles to the setup screen of another installed detector.
The [DET] key can also be used to switch screens.
―――
VLV On or
VLV Off
When the optional solenoid valve to shut off supply gas is installed,
hydrogen and air are shut off by the valve until ignition.
Opens the solenoid valve when “VLV On” is displayed and closes the valve
when “VLV Off” is displayed.
―――
