Shimadzu GC-2014 Instruction Manual

1 Installation
1.3 Gas Supply Plumbing
8
GC-2014
3. Gas supply pressures
Carrier gas 300 - 980 kPa (Hydrogen: 300 - 500 kPa)
Makeup gas 300 - 980 kPa
Hydrogen 300 - 500 kPa
Air 300 - 500 kPa
The relationship of kPa and bar is as follows
100 kPa = 1 bar
Convert units between kPa and kgf/cm
2
as follows.
1 kPa = 1.0
2
× 10
-2
kgf/cm
2
1 kgf/cm
2
= 98.1 kPa
Convert the units between kPa and psi as follows.
1 kPa = 1.45 × 10
-1
psi
1 psi = 6.89 kPa
NOTE

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
