Shimadzu GC-2014 Instruction Manual

16 Special Functions
16.7 Service and Maintenance
257
GC-2014
16.7.3.2 Parameter list
INSTALLATION POSITION
Range: 0−15, Default: 0
Specify the component installation location by entering a numeric value from 1 to 8 as
shown in Fig. 16.7.3.
Set “0” when a unit is not installed.
Set “15” when a unit is installed in a position not shown in Fig. 16.7.3.
Fig. 16.7.3 Component installation location
Changes are not in effect until the GC has been turned off and on.
NOTE

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
