Shimadzu GC-2014 Instruction Manual

17 Printing
17.4 Event No.
280
GC-2014
62
Turns on CAR1 gas saver.
Sets split ratio to value of CAR1 gas saver split
ratio 2.
Turns off CAR1 gas saver.
Returns split ratio to value of analysis
parameter.
63
Turns on CAR2 gas saver.
Sets split ratio to value of CAR2 gas saver split
ratio 1.
Turns off CAR2 gas saver.
Returns split ratio to value of analysis
parameter.
64
Turns on CAR2 gas saver.
Sets split ratio to value of CAR2 gas saver split
ratio 2.
Turns off CAR2 gas saver.
Returns split ratio to value of analysis
parameter.
71 Ignites frame. Extinguishes frame.
81 Turns on feedback of FTD 1. Turns off feedback of FTD 1.
82 Turns on feedback of FTD 2. Turns off feedback of FTD 2.
83 Turns on feedback of FTD 3. Turns off feedback of FTD 3.
84 Turns on feedback of FTD 4. Turns off feedback of FTD 4.
91 N/O contact between two contacts in one circuit N/C contact between two contacts in one circuit
92 N/O contact between two contacts in one circuit N/C contact between two contacts in one circuit
93
N/O contact between two contacts in one circuit
(option PRG)
N/C contact between two contacts in one circuit
(option PRG)
94
N/O contact between two contacts in one circuit
(option PRG)
N/C contact between two contacts in one circuit
(option PRG)
103 Closes CAR1 splitter control. Opens CAR1 splitter control.
104 Closes CAR2 splitter control. Opens CAR2 splitter control.
105 Turns On AC blower. Turns Off AC blower.
106 Closes air (solenoid valve). Opens air (solenoid valve).
109 Turns On AC CRG INJ. Turns Off AC CRG INJ.
110 Turns On AC CRG Column. Turns Off AC CRG Column.
111 Turns On AC Cooling fan. Turns Off AC Cooling fan.
131 Turns On DET #1 detector controller. Turns Off DET #1 detector controller.
132 Turns On DET #2 detector controller. Turns Off DET #2 detector controller.
133 Turns On DET #3 detector controller. Turns Off DET #3 detector controller.
134 Turns On DET #4 detector controller. Turns Off DET #4 detector controller.
141 Turns On CAR1* carrier gas. Turns Off CAR1* carrier gas.
142 Turns On CAR1 septum purge Turns Off CAR1 septum purge.
143 Turns On CAR2** carrier gas. Turns Off CAR2** carrier gas.
144 Turns On CAR2 septum purge. Turns Off CAR2 septum purge.
145 Turns On CAR3*** carrier gas. Turns Off CAR3*** carrier gas.
146 Turns On CAR3 septum purge. Turns Off CAR3 septum purge.
147 Turns On DET #1 makeup gas. Turns Off DET #1 makeup gas.
148 Turns On DET #1 H2. Turns Off DET #1 H2.
149 Turns On DET #1 Air. Turns Off DET #1 Air.
150 Turns On DET #2 makeup gas. Turns Off DET #2 makeup gas.
151 Turns On DET #2 H2. Turns Off DET #2 H2.
152 Turns On DET #2 Air. Turns Off DET #2 Air.
153 Turns On DET #3 makeup gas. Turns Off DET #3 makeup gas.
154 Turns On DET #3 H2. Turns Off DET #3 H2.
No. Meaning of “Event xx” (Example: Event 1) Meaning of “Event-xx” (Example: Event -1)
When the dual AFC (DAFC) is used as flow controller, the following carrier gas is turned On/Off.
* CAR1 L side ** CAR2 L side
*** When CAR1 is DAFC: CAR1 R side, When CAR1 is AFC and CAR2 is DAFC: CAR2 R side.

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
