18 Error Messages
18.1 Error Messages
295
GC-2014
Detector flame error
The detector flame (FID, FPD) has been extinguished. Check the gas supply, and ignite the
detector again. If the flame error occurs repeatedly, the hardware has failed. The system
cannot be used in this condition. Turn off the system and contact your Shimadzu
representative.
FPD errors
There is a problem with the FPD detector. Refer to FPD User’s Manual
.
Errors 4125-4128, that are related to abnormal current, cannot be recovered without turning
off the system once.
TCD errors
The difference in filament resistance is high between the TCD cells, and the detector cannot
be zeroed. If the zero point cannot be adjusted even by turning the adjuster on the right side
of the unit, the detector control unit may have failed. The system cannot be used in this
condition. Turn off the system and contact your Shimadzu representative.
Code Message CS
4109 DET#1 flame is out No
4110 DET#2 flame is out No
4111 DET#3 flame is out No
4112 DET#4 flame is out No
Code Message CS
4113 DET#1 FPD battery error Yes
4114 DET#2 FPD battery error Yes
4115 DET#3 FPD battery error Yes
4116 DET#4 FPD battery error Yes
4117 DET#1 FPD temperature error Yes
4118 DET#2 FPD temperature error Yes
4119 DET#3 FPD temperature error Yes
4120 DET#4 FPD temperature error Yes
4121 DET#1 FPD cooling fan error Yes
4122 DET#2 FPD cooling fan error Yes
4123 DET#3 FPD cooling fan error Yes
4124 DET#4 FPD cooling fan error Yes
4125 DET#1 FPD current error Yes
4126 DET#2 FPD current error Yes
4127 DET#3 FPD current error Yes
4128 DET#4 FPD current error Yes
Code Message CS
4201 TCD signal is out of range No
4202 TCD signal zero error No

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
