Shimadzu GC-2014 Instruction Manual

3 Installing Packed Columns and Setting Analytical Flow Lines
3.1 Installation Location for Packed Columns
32
GC-2014
Check which units the joints found on the column oven correspond to.
Fig. 3.1.2 shows the layout for the GC-2014ATF+SPL model.
Left and right sides viewed from the front of the unit are indicated as L (left) and R (right)
respectively.
Fig. 3.1.2 Column connecting joints (GC-2014ATF+SPL model)
SPL
Dual INJ
Dual FID
.4
LR
TCD
.4

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
