CLI – This example configures an IPv6 gateway, specifies the
management interface, configures a global unicast address, and then sets
the MTU.
Configuring an IPv6 General Network Prefix
The IPv6 General Prefix page is used to configure general prefixes that are
subsequently used on the IPv6 Configuration web page (see page 4-13) to
specify the network address portion of an interface address.
Command Usage
• Prefixes may contain zero-value fields or end in zeros.
• A general prefix holds a short prefix that indicates the high-order bits
used in the network portion of the address. Longer, more specific,
prefixes can be based on the general prefix to specify any number of
Console#config
Console(config)ipv6 default-gateway 2009:DB9:2229::240 36-24
Console(config)#ipv6 general-prefix rd 2009:DB9:2229::/48 36-12
Console(config)#interface vlan 1 24-2
Console(config-if)#ipv6 address rd 7279::79/64 36-14
Console(config-if)#ipv6 mtu 1280 36-26
Console(config-if)#ipv6 enable 36-10
Console(config-if)#end
Console#show ipv6 default-gateway 36-25
ipv6 default gateway: 2009:DB9:2229::240
Console#show ipv6 interface 36-22
Vlan 1 is up
IPv6 is enable.
Link-local address:
FE80::200:E8FF:FE90:0/64
Global unicast address(es):
2009:DB9:2229::79, subnet is 2009:DB9:2229:0::/64
Joined group address(es):
FF01::1/16
FF02::1/16
FF02::1:FF00:79/104
FF02::1:FF90:0/104
MTU is 1280 bytes.
ND DAD is enabled, number of DAD attempts: 1.
ND retransmit interval is 1000 milliseconds
Console#show ipv6 mtu 36-27
MTU Since Destination Address
1400 00:04:21 5000:1::3
1280 00:04:50 FE80::203:A0FF:FED6:141D
Console#
