ILE

ANAGEMENT

OMMANDS

20-17

delete

This command deletes a file or image.

Syntax

delete [unit:] filename

• filename - Name of configuration file or code image.

• unit - Stack unit. (Range: 1-8)

Default Setting

None

Command Mode

Privileged Exec

Command Usage

• If the file type is used for system startup, then this file cannot be

deleted.

• “Factory_Default_Config.cfg” cannot be deleted.

• A colon (:) is required after the specified unit number.

Example

This example shows how to delete the test2.cfg configuration file from

flash memory.

Related Commands

dir (20-18)

delete public-key (22-28)

Console#delete test2.cfg

Console#
