IP Settings Management. VLAN Any VLAN configured with an

IP address

IP Address 0.0.0.0

Subnet Mask 255.0.0.0

Default Gateway 0.0.0.0

DHCP Client: Enabled

Relay: Disabled

Server: Disabled

DNS Clinet/Proxy: Disabled

BOOTP Disabled

ARP

Enabled

Cache Timeout: 20 minutes

Proxy: Disabled

Unicast Routing RIP Disabled

Multicast Filtering IGMP Snooping Snooping: Enabled

Querier: Disabled

System Log Status Enabled

Messages Logged Levels 0-7 (all)

Messages Logged to Flash Levels 0-3

SMTP Email Alerts Event Handler Enabled (but no server defined)

SNTP Clock Synchronization Disabled

Table 1-2 System Defaults (Continued)

Function Parameter Default
