A
DDRESS
R
ESOLUTION
P
ROTOCOL
17-17
CLI - This router uses the Type specification “other” to indicate local
cache entries in the ARP cache.
Displaying ARP Statistics
You can display statistics for ARP messages crossing all interfaces on this
router.
Web - Click IP, ARP, Statistics.
Figure 17-7 ARP Statistics
Console#show arp 36-47
Arp cache timeout: 1200 (seconds)
IP Address MAC Address Type Interface
--------------- ----------------- --------- -----------
10.1.0.0 ff-ff-ff-ff-ff-ff other 1
10.1.0.11 00-11-22-33-44-55 static 1
10.1.0.12 01-02-03-04-05-06 static 1
10.1.0.19 00-10-b5-62-03-74 dynamic 1
10.1.0.253 00-00-ab-cd-00-00 other 1
10.1.0.255 ff-ff-ff-ff-ff-ff other 1
Total entry : 6
Console#
Table 17-2 ARP Statistics
Parameter Description
Received Request Number of ARP Request packets received by the router.
Received Reply Number of ARP Reply packets received by the router.
Sent Request Number of ARP Request packets sent by the router.
Sent Reply Number of ARP Reply packets sent by the router.
