IP R

OUTING

17-42

Web - Click Routing Protocol, RIP, Statistics.

Figure 17-18 RIP Statistics

Version Whether RIPv1 or RIPv2 packets were received from

this peer.

RcvBadPackets Number of bad RIP packets received from this peer.

RcvBadRoutes Number of bad routes received from this peer.

Table 17-7 RIP Information and Statistics (Continued)

Parameter Description
