D ISPLAYING I NTERFACE S ETTINGS FOR MSTP
10-25
CLI – This displays STA settings for instance 0, followed by settings for
each port. The settings for instance 0 are global settings that apply to the
IST (page 10-4), the settings for other instances only apply to the local
spanning tree.
Console#show spanning-tree mst 0 29-25
Spanning-tree information
---------------------------------------------------------------
Spanning tree mode: MSTP
Spanning tree enabled/disabled: enabled
Instance: 0
VLANs configuration: 2-4093
Priority: 32768
Bridge Hello Time (sec.): 2
Bridge Max Age (sec.): 20
Bridge Forward Delay (sec.): 15
Root Hello Time (sec.): 2
Root Max Age (sec.): 20
Root Forward Delay (sec.): 15
Max hops: 20
Remaining hops: 20
Designated Root: 32768.0.0000E8AAAA00
Current root port: 1
Current root cost: 10000
Number of topology changes: 12
Last topology changes time (sec.):303
Transmission limit: 3
Path Cost Method: long
---------------------------------------------------------------
Eth 1/ 1 information
---------------------------------------------------------------
Admin status: enabled
Role: root
State: forwarding
External admin path cost: 10000
Internal admin path cost: 10000
External oper path cost: 10000
Internal oper path cost: 10000
Priority: 128
Designated cost: 0
Designated port: 128.4
Designated root: 32768.0.0000E8AAAA00
Designated bridge: 32768.0.0000E8AAAA00
Fast forwarding: disabled
Forward transitions: 2
Admin edge port: disabled
Oper edge port: disabled
Admin Link type: auto
Oper Link type: point-to-point
Spanning Tree Status: enabled
.
.
.
